In Vehicle Walkie Talkie

Our factory specializes in manufacturing of In Vehicle Walkie Talkie. Welcome to buy In Vehicle Walkie Talkie from Lisheng. Every request from customers is being replied within 24 hours.In Vehicle Walkie Talkie is a wireless walkie-talkie targeted at the automotive market. It mainly consists of two parts, one is the host computer placed inside the vehicle, and the other is a portable handheld intercom. The device communicates using digital or analog technology, allowing for high-quality voice communication.

Model:UT858

Send Inquiry

Product Description

Lisheng is one of the professional In Vehicle Walkie Talkie manufacturers and suppliers in China. Our products are CE certified and have in stock of factory. In Vehicle Walkie Talkie is a wireless walkie-talkie targeted at the automotive market. It mainly consists of two parts, one is the host computer placed inside the vehicle, and the other is a portable handheld intercom. The device communicates using digital or analog technology, allowing for high-quality voice communication. Using In Vehicle Walkie Talkie can facilitate real-time communication between personnel within the vehicle, which can improve the efficiency of personnel coordination and vehicle dispatching, and optimize vehicle operation management. It is a professional-level wireless communication device that uses digital or analog technology and is suitable for situations where real-time communication is required while the vehicle is driving, such as taxis, logistics parks, buses and other fields. Below is a description and uses of this product.

Main features of this product:

1. High-quality voice and high-sensitivity microphone can achieve better communication effects by improving voice clarity.

2. Reduce interference, which can effectively resist interference from other wireless devices and ensure communication quality.

3. Long communication distance, suitable for a wide range of occasions.

4. Digital or analog mode can be selected to adapt to different communication specifications and requirements.

5. It is simple and easy to operate and can be used without complicated settings and configurations.


In Vehicle Walkie Talkie is easy to install and use. Vehicles can be installed quickly without unnecessary construction and configuration operations, shortening startup and application time. In Vehicle Walkie Talkie is an efficient, convenient and practical vehicle-mounted wireless communication device. It has been widely used in various types of vehicles, showing unparalleled efficiency and expressiveness.


UT858 is a professional mobile radio, which is designed to be installed into a vehicle and connected to an external antenna mounted outside the automobile.


It's flexible to adapt to different environments, keeping your people connected. Clear audio, high sensitivity, and excellent quality ensure efficient communication. This cost-effective mobile radio is with rich functions like Scrambler Function、PTT ID、SOS function etc., supply great help in moving communication.

Product Specification:

Frequency Range

VHF:136-174MHz

UHF:350-390MHz

400-470MHz

450-520MHz

Channel Capacity

199

Channel Zone No.

32

Channel Spacing

25kHz/12.5kHz

Antenna Impedance

50Ω

Operating Voltage

DC 13.8V±15%

Current Drain



Standby mode

≤0.3A

Receiving mode

≤0.8A

Transmitting mode

≤ 4A (10W) ≤6A (25W) ≤ 10A (50W)

Frequency Stability

±2.5ppm

Operating Temperature

-30℃~+60℃

Dimension (H×W×D)

158mm×155mm×40mm

Weight

1.14 Kg

Transmitter

Carrier output power

50W/25W/10W

45W/25W/10W

Modulation Mode

16KΦF3E/11KΦF3E

Modulation Distortion

≤5%

Maximum Frequency Deviation

≤5kHz/2.5kHz

Transmitting SNR

≥40/35dB

Spurious & Harmonics

-36dBm<1GHz, -30dBm>1GHz

Adjacent Channel Power

≤-70dB/≤-60dB

Receiver

Sensitivity (12db SINAD)

≤0.20uV/≤0.25uV

Audio Power

≥1.0W

Audio Distortion

≤5%

Receiving SNR

≥45/40dB

Adjacent Channel Selectivity

≥70dB/≥60dB

Spurious Response Rejection

≥70dB

Intermodulation Rejection

≥65dB

Product Details:


Control Panel Separated Installed: The control panel can be mounted on the dashboard without the radio chassis, it’s very convenient when space is constraint.

5 Programmable backlight buttons

Larger Dot Matrix LCD display, Dual Display

Emergency Alarm Function

1750 Tones

Audio Compandor

Talk Around function

Remote Stun, Remote Kill, Remote Revive

Busy Channel Lockout

Keypad Locked

Squelch Tail Elimination

Time-out-timer (TOT)

Manual/PC Programmed

Multiple Scan Modes

Software Read and Write Password

Versatile Encryption Signaling: DTMF Encode & Decode, 2-Tone, 5Tone

Networking: Individual Call, Group Call, All Call

Scrambler Function

PTT ID

SOS function

Our Inspection and Packing Section:


We are committed to delivering top-quality two-way radio products, ensuring each product meets the highest standards through rigorous inspection and packaging processes. Our inspection and packaging team bears the responsibility of ensuring customers receive reliable products, providing worry-free user experience.

Inspection Process:

1、Visual Inspection: Each two-way radio undergoes a thorough visual inspection to ensure flawless aesthetics that align with the company's brand image.

2、Functionality Testing: Our inspection team conducts comprehensive functionality tests on every radio, ensuring all features operate correctly. This includes key functions such as audio quality, signal strength and channel switching.

3、Durability Testing: Products undergo durability tests to ensure they function properly in various environmental conditions, including extreme temperatures, humidity, and vibrations.

4、Battery Performance Testing: Battery life is crucial for radio performances. Strict performance tests are carried out on batteries to ensure reliable and extended use.

Packaging Process:

1、Anti-Static Packaging: Each radio undergoes anti-static packaging to prevent electrostatic damage during transportation.

2、Environmentally Friendly Packaging: Committed to sustainability, our packaging materials adhere to international environmental standards.

3、Shock-Resistant Packaging: Professional shock-resistant packaging is employed during transportation to prevent damages to products.

4、Integrity Check: The packaging team performs a final integrity check to ensure products remain intact and undamaged after the packaging process.


Our inspection and packaging processes aim to surpass customer expectations, ensuring that every two-way radio received has undergone rigorous testing and meticulous packaging as a high-quality product.



In Vehicle Walkie Talkie

Customer Evaluation and Feedback:Satisfied customers are our number one priority
